Motorized Cleaning Head Drop Testing Machine

Standard
Clause 21.101 of IEC 60335-2-3 Household and similar electrical appliances - Safety: Part 2-3: Particular requirements for electric ions, Clause 15.101 of IEC 60335-2-2 Household and similar electrical appliances - Safety: Part 2-3: Particular requirements for Vacuum cleaners and water-suction cleaning appliances.

Application
It is used to test the mechanical strength of the motorized cleaning heads of water-suction cleaning appliances.

Test Sample
Motorized cleaning heads of water-suction cleaning appliances.

Feature
Hang up the motorized cleaning heads of water-suction cleaning appliances, and make sure the control device is horizontal to the bottom plate, then drop from a height of 100 mm and fall to a rigid support plate which is at least 15 mm thick.

-1000 times on its right side
-1000 times on its left side
-1000 times on its front face
-1000 times on its cleaning surface

Parameters

Model HJ0611
Input Power AC220V 50HZ
Drive Mode Electric moto driven, the drop action is achieved through the cam mechanism.
Test Cycles 1~999999, adjustable
Working Speed ≤20 r/minute
drop ping Height 100mm
drop ping Face right side, left side, front face, cleaning surface, process 1000 cycles for each side
Support Steel Plate Thickness >15mm, weight >15kg
Dimension & Weight 600*600*1250mm,120kg
